| Application area | Type | Cable | Conductor cross-section (mm²)* | Crossed conductor cross-section (mm²) | Max. outer sheath diameter (mm) |
|---|---|---|---|---|---|
| 24 kV | KB95 | Polymeric / PILC (1-core) | 95 - 1000 | N/A | 87 |
| Polymeric / PILC (3 x 1-core) | 120 - 300 | N/A | 40 | ||
| Polymeric / PILC (3-core) | 120 - 300 | 240 | 87 |
| Dimension A | Dimension B | Test certificates | |
|---|---|---|---|
| 1500 | 320 |  | CENELEC HD 629 (1) E DIN EN 60455 CENELEC HD 629 (2) CENELEC HR 629 (3) |
* Please note: the diameter of the outer sheath and the supplied cable modules is decisive.
LoviSil® Branch Joint KB95 (12/20(24)kV)
| Parts | Inner joint, Outer joint, Protolin resin, Lovisil silicone, separator set, closing foam, tape, connector, braided sleeve |
|---|---|
| Origin | Netherlands |
| Packaging | Box |
| Shelf life | 24 months |
| Length (mm) | 1572 |
| Width (mm) | 367 |
| Height (mm) | 283 |
