| Application area | Type | Cable | Conductor cross-section (mm²)* | Crossed conductor cross-section (mm²) | Max. outer sheath diameter (mm) |
|---|---|---|---|---|---|
| 36 kV | MK125 | Polymeric / PILC (1-core) | 70 - 500 | N/A | 58 |
| Polymeric / PILC (3-core) | 70 - 500 | N/A | 120 |
| Dimension A | Dimension B | Test certificates | |
|---|---|---|---|
| 1850 | 310 |  | CENELEC HD 629 E DIN EN 60455 |
* Please note: the diameter of the outer sheath and the supplied cable modules is decisive.
LoviSil® Extended Joint MK125 (18/30(36)kV)
| Parts | Base module: inner joint, outer joint, tube set, earth screen, push on applicator, tape, cable cleaning tissues. Separately: connector(s), resin module(s) & cable modules. |
|---|---|
| Origin | The Netherlands |
| Packaging type | Box |
| Shelf life | 24 months |
| Length (mm) | 1670 |
| Width (mm) | 430 |
| Height (mm) | 340 |
